外形尺寸  Dimension

L910*W690*H490mm       L910*W690*H490mm

重量        Weight

約95KG                about 95KG

顯示方式   Display

中英文，觸摸屏操作 Chinese and English, touch screen operation

電源       Power

220V／2000W             220V／2000W

切割長度 cutting length

10-100000MM             10-100000MM

前后端剝皮長度 front/rear end stripping length

前端：1-300，后端1-180MM    front end :1-300mm

Rear end:1-180mm

剝線范圍 stripping range

4-25平方mm^{2                       4}

自動調節線芯，不同規格線纜無需更換刀具4-25mm2 Automatic adjustment of the core,ifferent specifications of the cable without changing the blade

可剝層次 peel level

1-8層              1-8layers

導線類型 cable type

新能源線、電纜線、同軸線、電力線等 New energy cable, cable , coaxial cable , power line, etc

切割深度精度 Cutting depth accuracy

0.01MM

切斷精度 cutting accuracy

變動范圍：1mm+切斷長度x0.2%以下  Range of fluctuation:1mm+   cutting length x0.2% below

導管直徑 conduit diameter

6-14MM(旋刀導管6-12mm)    6-14MM(conduit of rotaty blade6-12mm)

驅動方式 driving way

伺服驅動   servo drive

切剝方式 cut strip way

移動刀架切剝+旋切 Move the knife  rest  to peel + srotary cutting

刀具      Blade

4片進口高速鋼,2片鎢鋼 4pcs Imported high speed steel; 2pcs tungsten steel

生產率（次／小時） Productivity(pcs/h)

依作業線總長及作業程序不同，最少可達300-500PCS/小時

Up to 300-500pcs/hour, depending on the length of the line and operating procedures

送線方式  wire feeding way

皮帶送線，線纜無壓印無刮痕！ Belt feed line, cable no impression no scratch!
